1. Core Scanning & Probe Parameters

• Probe Configuration: Ultra-Wide Linear Probe (color Doppler version) with 256 high-precision elements, 80mm ultra-wide probe head, and dual-frequency adjustment (7.5MHz/10MHz). 7.5MHz balances resolution and penetration, while 10MHz delivers high clarity for superficial tissues.
• Imaging Range: Adjustable linear scanning depth (20-60mm) to adapt to diverse superficial tissue thicknesses; 80mm linear field of view enables large-area observation, reducing the need for probe movement and improving examination efficiency.
• Physical Probe Specs: Probe net weight 250g, with an ergonomic design for comfortable handheld operation during long examinations.

2. Imaging Quality & Optimization Functions

• Imaging Modes: Supports B, B/M, Color, PDI (Power Doppler Imaging), and PW (Pulsed Wave Doppler) modes, covering static tissue observation, dynamic monitoring, and blood flow detection for multi-dimensional diagnosis.
• Imaging Foundation: 256-level image gray scale accurately reproduces subtle tissue density differences; 18 frames/second (18f/s) frame rate ensures smooth real-time imaging, capturing dynamic changes of superficial tissues clearly.
• Image Adjustment: Equipped with multi-dimensional optimization tools, including Gain (30dB-105dB), 8-level Dynamic Range (40-110), and 5-level Noise Reduction (0-4), effectively reducing image noise and enhancing layering for precise lesion identification.

3. Clinical Functions & Data Management

• Measurement Functions: Supports distance, area, obstetrics, and other clinical measurements, providing accurate quantitative data to assist in evaluating lesion size, tissue thickness, and physiological indicators.
• Data Storage: Images and videos are directly stored on mobile phones or tablets, eliminating the need for additional storage devices. This design facilitates on-site review, quick case sharing, and easy data archiving for follow-up comparison.

4. System Compatibility & Physical Specifications

• Display & Compatibility: Adapts to smartphone or tablet screens; compatible with iOS, Android, and Windows operating systems, enabling flexible connection to various terminal devices and reducing operational learning costs.
• Power Supply: Equipped with a built-in 4200mAh lithium battery, supporting 3.5 hours of continuous operation, fully covering daily clinical examination needs without frequent charging.
• Physical Dimensions: 156mm×60mm×20mm compact size, 250g net weight, ergonomic for one-hand handheld operation, easy to carry in a medical bag for bedside, home visit, or field medical services.
